POWER HD WP-23KG Coreless Motor 319.4 oz  / .12 Titanium Gear Digital Servo
POWER HD WP-23KG Coreless Motor 319.4 oz  / .12 Titanium Gear Digital Servo
POWER HD WP-23KG Coreless Motor 319.4 oz  / .12 Titanium Gear Digital Servo
Power HD

POWER HD WP-23KG Coreless Motor 319.4 oz / .12 Titanium Gear Digital Servo

Regular price $39.89 $0.00 Unit price per
use code "chicago10" and save 10% off your order plus Free Shipping
WP-23

Power HD WP-23KG Waterproof High Torque Digital Servo

  • WP-23KG is the hot sale in waterpoof servo series. Its purpose to enhance the torque and gear strength , and offer better durability and cost-effective.
  • Its waterproofness and gear strength were verified by many players' actual testing. Crawler players call it as "Never Gear Stripped Popeye"  (Torque: 23KG, Speed:0.12S/60°, Steel Gear, 100% Waterproof servo)
WP2303

Specifications

  • Torque(4.8V): 18.0 kg-cm (250 oz/in)
  • Torque(6.6V): 23.0 kg-cm (319.4 oz/in)
  • Speed: 0.14 sec/60° (4.8V) │ 0.12 sec/60° (6.6V)
  • Operating Voltage: 4.8 ~ 6.6 DC Volts
  • Weight: 75 g (2.65 oz)
  • Horn gear spline: 25T/ψ5.80
  • Limit angle: 180°± 10°
  • Operating travel: 90°(1000~2000 μsec)
  • Materials of the gear: Titanium & Steel
  • Bearing Type: Ball Bearing x 2
  • Motor Type: DC Motor (NOT brushless)
  • Gear Type: Copper & Aluminum Operating
  • Temperature: -20℃~60℃
  • Connector wire length: 250mm/9.8inch
  • Working frequence: 1520μs / 333hz
  • Dimensions: 40.7 x 20.5 x 38.5 mm ( 1.60 x 0.80 x 1.49 in)

Note:
Please be sure to avoid locked-rotor when using servo, locked-rotor means that artificially or machine obstructs the servo to rotate normally, the locked-rotor will lead to internal current increased several times and the temperature increases, servo will burn out.

  • Used For: 1/10 1/8 scale Crawler / Buggy / Truck
  • Material: Middle Aluminum Casing With Plastic Top and Bottom
  • Color: Blue & Black
